Features

• Numerical electric control system.
• Meets customer’s requirement of single spindle and large package.
• Wide application of processing materials. Applies for all kinds of coarse yarn, such as polyester, polyamide, blended yarn with wool and cotton, glass fiber, and so on.
• Automation control. Optimizes the electrical control system. Controls the spindles, winding and yarn guiding mechanism with high accuracy. Sets and monitors the main technical parameters such as spindle speed and twist on the panel. Achieves the changing of winding and twist by PLC feedback closed-loop control. Runs smoothly. Servo-motor drives the yarn guide traverse. By direct connecting of flexible coupling and ball screw and positive inversion of motor to guarantee the positioning accuracy and the traverse motion of guide rod.
  1. Wide technological adaptability. Stepless adjustment of angle of wind, forming length, short stroke length, long–short stroke frequency, and so on. Easy alteration and satisfactory to optimize different products.
  2. 2–3 strands yarns will twist and merge at the same time.
  3. Traverse servo motor transmission and nice winding shaping.
  4. Various forming modes to satisfy different yarn shaping demands of clients.
  5. Autostopper when yarn is broken.
